**READY FOR IMMEDIATE DELIVERY**
1 x only NEW 2024 Isuzu NPR 65/45-190 Crew Cab (DUAL CAB) TIPPER
GVM: 6,500 Kg (Optional: 4,500 Kg)
GCM: 10,000 Kg (Optional: 9,000 Kg)
Engine:  Isuzu 4HK1-TCN - 5.2L 4 Cylinder Turbo Diesel
Transmission: Isuzu MZZ-6F - 6 Speed Manual Transmission
Power: 190 Hp 140 kW @ 2,600 RPM
Torque: 513 Nm @ 1,600 2,600 RPM
BODY
Genuine Isuzu Tipper Body
Internal Length 3,600 mm
Internal Width 2,160 mm
Internal Height 370 mm
All Steel Body with Drop Sides
Auto Release Two-Way Tailgate
Auto Release Body Lockdown Hook
Shovel Rack
LHS and RHS Rope Rails
Non-Slip Side Steps
20 Sec. Raise / 20 Sec. Lower Time
Cubic Volume 2.8 m³
Deck Plate Thickness 3.2 mm
Side / Front / Tail Plate Thickness 2.3 mm
INCLUDING
Genuine Reverse Camera
Rubber floor mats
Canvas seat covers
Stock # B86047
Note:  Price is NOT including on road costs

2024 ISUZU NPR65/190

**IN STOCK AND READY FOR IMMEDIATE DELIVERY**
TRUCK:  1 x only NEW 2024 Isuzu FVZ 240-300 AUTO - 6x4 - 7.8 litre, turbo / intercooled, 300hp, 6 speed ALLISON AUTOMATIC
GVM: 24,000kg
GCM: 36,000kg
BODY:  14,000Ltr Hot Dip Galvanized Steel tank features as follows:
Low prole tank design for low centre of gravity enhancing vehicle stability. 3x 5mm crossway tank bae walls to minimize front and rear water surge.1x 5mm longitudinal bae wall full length of tank to minimize sideways water surge. Splash rim integrated all around at the top of tank. All tank surfaces are Hot Dip Galvanized for corrosion protection. The exterior of the tank is top  coated white with a two-pack topcoat paint system to match the truck cab. Tank to be mounted via a exible mounting system using spring loaded mounts either side of the body front and rear to allow for chassis ex. 3D CAD design and Trailer WIN used to ensure tank strength and axle weight distribution is perfectly balanced. Suction hose storage for 80mm suction hose assemblies. 2x 80mm suction hose assemblies to be supplied. High clearance, Heavy-duty mudguards and white rubber mud aps tted over drive group. All mudguards inc. steer to be tted with spray suppression.
TANK: Water level sight gauge tted into tank at front and rear. Front gauge to be tted on drivers side of tank. Bright coloured oat tted into sight gauges. Funnel with 80mm (3'') hydrant top-ll system including regulation air gap and non return check valve. Hydrant ll to comply with water authority regulations. System can be used with hydrant stand pipes, overhead gantry ll or self lling with water pump.
PUMP SYSTEM: Hot shift PTO to suit automatic transmission Allison 3000 (steel tank). System includes hydraulic pump, ow control valve, pressure relief valve and check valve. HYDAC hydraulic oil tank with integrated hydraulic oil cooler. Tank tted with return cartridge lter, oil level gauge, temperature gauge & 20 litres of 68 grade hydraulic oil. Pump engaging switch tted into the in cab control panel in easy reach of seated operator. Pump engaging switch tted externally LHS of body near suction system in easy reach of operator standing on ground.(to assist operator with suction lling and hose reel operation etc.)Hydraulic system to be mounted in a protected and accessible position. Hydraulic system meets the AS2671-2002 and is tested, rated and suitable for water pump. Hydraulic system in operation is below the permissible noise level of 85dB. Australian made Southern Cross 100x65x250 heavy duty cast iron water pump, approximately 2,200 LPM at pump, total 60 MTR head and 86 PSI. Water pump to beclose-coupled to hydraulic drive Permco motor (Made in USA). Flexible bellows tted between tank and pump to permit ease of removal of the pump if required and to isolate pump vibration. Enables the driver to adjust the hydraulic driven water pump speed at will from the cabin. System capable of controlling hydraulic motor speed over the entire engine speed range and is also capable of being overridden by the accelerator pedal. Water pump pressure relief valve tted (steel tank) to allow continuous safe operation of the water pump even when all sprays are off thus preventing damage to water pump seal due to heat build up and pump cavitation.
SUCTION PIPEWORK: 80mm (3'') Pump suction system (steel tank) positioned on a 45 degree downward facing position for easy suction hose connection. The tank return line is to be plumbed directly into the tank wall. System capable of lling tank from water supplies such as rivers and holding dams and the tank can also be drained from this point. Coupling is 80mm male cam lock.
PRESSURE PIPEWORK: 80mm (3'') pipe work to be hot dip galvanised to match the incredible lifespan of the galvanised tank. 1x 80mm (3'') under body pressure fed v-jet spray bar tted with 14 brass v-jets and removable ends for ushing. Spray bar mounted on chains for exibility on rough terrain.1x 80mm (3'') under body pressure fed v-jet spray bar tted with 14 brass v-jets and for ushing. Spray bar mounted on chains for exibility on rough terrain.
SPRAYS: 1x 80mm (3'') Rear centre deector fan spray. Fan spray, on roll groove and camlock ttings for full adjustment of spray. Fan spray to have adjustable clamp for controlling water volume, e.g. ne or heavy spray patterns. 2x 80mm (3'') rear batter deector fan sprays. Sprays on roll groove and camlock ttings for full adjustment. Fan sprays to have adjustable clamp for controlling water volume, e.g. ne or heavy spray patterns. 2x 50mm forward mounted gutter usher sprays mounted as high as possible under bumper at front of truck for washing down roads etc. (steel tank)
CANNON: 65mm electric Nitro water cannon including air actuated on/off valve. 8 way joy stick controller mounted in easy reach of operator for simple UP/DOWN/LEFT/RIGHT and electric nozzle for FOG/JET STREAM spray patterns.
OUTLETS;: 1x 80mm (3'') Pressure outlet with wafer buttery valve and cam-lock. System capable of emptying tank and pumping out to external equipment.1x 20mm (3/4'') Pressure outlet with ball valve with tap connection. (For concrete saw, pressure washers etc)
CONTROLS;: All sprays to be air over air actuated. Air lines connected to illuminated switches and mounted in a control box for in cab operation. Control box to be mounted in easy reach of operator.
HOSE REEL; Heavy duty high volume manual rewind hose reel tted with 20m of 25mm industrial wash down  hose and adjustable re ghting nozzle. Manual ball valve tted in supply line..
ELECTRICAL; Heavy duty electrical harness system using Deutsch connectors and premium automotive wire for added protection in corrosive environments. IP66 rated Power distribution module tted with fuses & relays to run water truck system whilst safeguarding OEM vehicle and electrical components. Heavy duty Hella self-adjusting reverse alarm wired to only operate when reverse gear engaged.
LIGHTING; Sub frame tted with LED combination tail lights including reverse. Lights mounted into steel channel for protection.6x LED side clearance lights and 2x indicator lights mounted into side rail. 1 x number plate light. All wiring to be in conduit and lighting to comply with the ADR for 24hr operation. 1 x Hella LED amber beacon light tted to top rear of tank for ultimate visibility. 1x Hella LED rear work light tted to top rear of tank for lighting up the rear platform.
TOOLBOX: Heavy duty black powder coated steel tool box. Tool box tted with fold out door and lockable tee handles. Approx. tool box dimensions: L800mm x W500mm x D500mm. 2 x Sets of keys supplied (all compartments keyed alike).
RUSTPROOFING: Metal sub frame and pipework to be hot dipped galvanized. Nylon spacer strips to run full length between tank sub frame and truck chassis rails to prevent corrosion. All ttings to be made from non-corrosive materials such as brass and aluminium.
STYOCK # B90110
Note:  Price is NOT including on road costs.

2024 ISUZU FVZ 240-300 AUTO

* READY FOR IMMEDIATE DELIVERY

1 x only NEW 2024 Isuzu FYJ 300-350 AUTO (8×4), 9.8 litre, turbo / intercooled, SiTEC350hp, 6 speed Allison AUTOMATIC.
REAR SUSPENSION:  Hendrickson HAS461 AIRBAG rear suspension.
***ARTICULATED*** HOOKLIFT UNIT
GVM:  30,000kg
GCM:  42,500kg
POWER:  257kw @ 2,000 RPM
TORQUE:  1,422NM @ 1,200 1,500 rpm
Fitted with a new 2024 Hook Lift HL 20A  ARTICULATED HOOKLIFT UNIT
Link to specs of HOOKLIFT UNIT https://west-trans.com.au/product/hl-20a/
Standard Equipment
Working load limit (WLL) = 20,000kg
Tare weight = 2,925kg
Hydraulic working pressure = 245 BAR (3,500psi)
Pump flow rate = 65 70L/min
oil tank capacity = 80L
To suit bin lengths 3,800 to 6,500mm
Bin rail width = 1,060mm
Tunnel height = 105mm
Lift bar height = 1,450mm
INCLUDING THE FOLLOWING OPTIONS
Remote tarp tower
Slimline amber beacon
Genuine Reverse Camera
Canvas Seat Covers
Rubber Floor Mats
STOCK # B84930
Note:  Price is NOT including on road costs.

2024 ISUZU FYJ 300-350
